IFLI 300/500 V ALSECURE

Products

IFLI 2x1.5/1.5

Nexans ref. 10021817 - Country ref. 1067234

  • Packaging: Box (50m)
  • Conductor diameter: 1.4 mm
  • Nominal outer diameter: 8.5 mm
  • Approximate weight: 9.0 kg/100m
  • Number of cores: 2
  • Fire load: 1100 MJ/km



IFLI 2x2,5/2,5

Nexans ref. 10021818 - Country ref. 1067235

  • Packaging: Box (50m)
  • Conductor diameter: 1.8 mm
  • Nominal outer diameter: 9.2 mm
  • Approximate weight: 12.4 kg/100m
  • Number of cores: 2
  • Fire load: 1400 MJ/km



IFLI 3x1,5/1,5

Nexans ref. 10021821 - Country ref. 1067238

  • Packaging: Box (3000m)
  • Conductor diameter: 1.4 mm
  • Nominal outer diameter: 8.7 mm
  • Approximate weight: 13.4 kg/100m
  • Number of cores: 3
  • Fire load: 1400 MJ/km



IFLI 3x2,5/2,5

Nexans ref. 10021822 - Country ref. 1067239

  • Packaging: Box (50m)
  • Conductor diameter: 1.8 mm
  • Nominal outer diameter: 9.9 mm
  • Approximate weight: 19.6 kg/100m
  • Number of cores: 3
  • Fire load: 1800 MJ/km



IFLI 4x1,5/1,5

Nexans ref. 10021823 - Country ref. 1067240

  • Packaging: Coil (3000m)
  • Conductor diameter: 1.4 mm
  • Nominal outer diameter: 9.0 mm
  • Approximate weight: 15.7 kg/100m
  • Number of cores: 4
  • Fire load: 1400 MJ/km



IFLI 4x2,5/2,5

Nexans ref. 10021824 - Country ref. 1067241

  • Packaging: Coil (5000m)
  • Conductor diameter: 1.8 mm
  • Nominal outer diameter: 10.9 mm
  • Approximate weight: 22.6 kg/100m
  • Number of cores: 4
  • Fire load: 1800 MJ/km



IFLI 2x1.5/1.5

Nexans ref. 10021807 - Country ref. 1067242

  • Packaging: Drum (500m)
  • Conductor diameter: 1.4 mm
  • Nominal outer diameter: 8.5 mm
  • Approximate weight: 9.0 kg/100m
  • Number of cores: 2
  • Fire load: 1100 MJ/km



IFLI 2x2,5/2,5

Nexans ref. 10021808 - Country ref. 1067243

  • Packaging: Drum (450m)
  • Conductor diameter: 1.8 mm
  • Nominal outer diameter: 9.2 mm
  • Approximate weight: 12.4 kg/100m
  • Number of cores: 2
  • Fire load: 1400 MJ/km



IFLI 3x1,5/1,5

Nexans ref. 10021811 - Country ref. 1067246

  • Packaging: Drum (350m)
  • Conductor diameter: 1.4 mm
  • Nominal outer diameter: 8.7 mm
  • Approximate weight: 13.4 kg/100m
  • Number of cores: 3
  • Fire load: 1400 MJ/km



IFLI 3x2,5/2,5

Nexans ref. 10021812 - Country ref. 1067247

  • Packaging: Drum (250m)
  • Conductor diameter: 1.8 mm
  • Nominal outer diameter: 9.9 mm
  • Approximate weight: 19.6 kg/100m
  • Number of cores: 3
  • Fire load: 1800 MJ/km



IFLI 4x1,5/1,5

Nexans ref. 10021813 - Country ref. 1067248

  • Packaging: Drum (250m)
  • Conductor diameter: 1.4 mm
  • Nominal outer diameter: 9.0 mm
  • Approximate weight: 15.7 kg/100m
  • Number of cores: 4
  • Fire load: 1400 MJ/km



IFLI 4x2,5/2,5

Nexans ref. 10021814 - Country ref. 1067249

  • Packaging: Drum (200m)
  • Conductor diameter: 1.8 mm
  • Nominal outer diameter: 10.9 mm
  • Approximate weight: 22.6 kg/100m
  • Number of cores: 4
  • Fire load: 1800 MJ/km



Description

Description

Standards

  • Test
    IEC 60332-3; IEC 60754; IEC 61034
  • National
    NEK 591

Halogen free installation cable for indoor and outdoor use, but not suitable to be buried in the ground. IFLI is a halogen free version of PR Pluss.



Core identification:

2 conductors: Blue - brown

3 conductors: Black - brown - grey

4 conductors: Blue - brown - black - grey

Characteristics

Characteristics

Construction characteristics

Construction characteristics

Conductor material
Bare copper
Conductor shape
Circular
Core identification
Colours
Halogen free
Yes
Insulation
PE
Lead free
Yes
Material of filler / inner sheath
PE
Screen
Longitudinal aluminium tape + copper wire
Sheath colour
White
Type of conductor
Circular, solid

Usage characteristics

Usage characteristics

Flame retardant
IEC 60332-3 Cat. C
Maximum operating temperature
70 °C
RoHS compliant
Yes
