PN JetSet in Bucket
PN JetSet 3G1.5 in Bucket B2
Nexans ref. 10166697 - Country ref. 1060450
- Packaging: Reel in a box (150m)
- Conductor diameter: 1.6 mm
- Nominal outer diameter: 3.0 mm
- Approximate weight: 6.3 kg/100m
- Length: 150 m
PN JetSet 3G2.5 in Bucket B2
Nexans ref. 10166698 - Country ref. 1060451
- Packaging: Reel in a box (100m)
- Conductor diameter: 2.0 mm
- Nominal outer diameter: 3.6 mm
- Approximate weight: 9.9 kg/100m
- Length: 100 m
PN JetSet 3G6 in Bucket B2
Nexans ref. 10241986 - Country ref. 1060455
- Packaging: Reel in a box (50m)
- Conductor diameter: 3.0 mm
- Nominal outer diameter: 4.6 mm
- Approximate weight: 19.8 kg/100m
- Length: 50 m
PN JetSet 4G2.5 in Bucket B2
Nexans ref. 10166700 - Country ref. 1060453
- Packaging: Reel in a box (80m)
- Conductor diameter: 2.0 mm
- Nominal outer diameter: 3.6 mm
- Approximate weight: 13.2 kg/100m
- Length: 80 m
Description
Description
Standards
-
ProductEN 50525-2-31
-
TestIEC 60332-1-2
Field of use:
For installation inside conduits in buildings.
PN JetSet consists of 3 or 4 PN-wires with different colour coding, which are spooled together in our unique cable-bucket. When installing, 3 or 4 wires are pulled simultaneously into conduits, simplifying installation significantly.
PN JetSet have the same good installation and dismantling properties as the well known PN Jetline.
Nominal diameter denotes values for each conductor.
Colour combinations:
3 cores: Blue - brown - green/yellow
4 cores: Blue - brown - black - green/yellow
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Electrical characteristics
Electrical characteristics
Usage characteristics
Usage characteristics
