GRHSQ-K-DGNRV 24/T12 62,5um-OM1 S12
GRHSQ-K-DGNRV 24/T12 62,5um-OM1 S12
GRHSQ is a loose tube slotted core fibre optical cable. The cable type is intended for use in regional, urban, area and property networks.
Read more- Nexans ref. : 10559057
- Country ref. : 1082111
- EAN : 7330000083028
Description
Description
Standards
-
ProductEN 50173; IEC 60794
-
TestIEC 60754-2; IEC 60793; IEC 61034
-
InternationalITU-T Rec. G.650; ITU-T Rec. G.652
-
NationalSS 424 18 86
The cable type is longitudinally water-blocked and intended for combined indoor as well as outdoor use (in ducts). The design can incorporate 4 to 192 fibres in coloured loose tubes. The individually coloured fibres are tubed in groups of maximum 24, and placed into in a slotted core profile of polyethylene, which is extruded onto a dielectric fibre reinforced strength member (FRP). The cable type is longitudinal water-blocked through the use of water-swellable materials and sheathed with halogen-free flame-retardant polymeric compound. GRHSQ meets the requirements for CPR Dcas2d2a2. The cable emits no corrosive gases and has low smoke production during fire.
Quality and environmental management system
Certified according to ISO 9001, IRIS, ISO/TS 16949 and ISO 14001.
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Dimensional characteristics
Dimensional characteristics
Mechanical characteristics
Mechanical characteristics
Usage characteristics
Usage characteristics
Resources
Resources
Documentation
Selling & delivery Information
The outer sheath of the cable is marked with cable type, manufacturer, identification number and meter marking.
The cable is delivered on wooden recyclable drums in lengths according to arrangement. The drum is marked with the cable type, length, rolling direction and installation information. Cable ends closed with end cap.
Declaration of Performance
- Declaration of Performance n� : 1000119-SEGR
- Certification Date : 6/14/18
- AVCP (Assessment and Verification of Constancy of Performance) : System 3
- Notified body : 0366
- Declared performance : Dca-s2,d2,a2
