G4-G657A1 ID 4,1mm B2ca wh B2 350
G4-G657A1 ID 4,1mm B2ca wh B2 350
Unibundle cable with watertight glass yarns - up to 12 fibres
Read more- Nexans ref. : 10567785
- Country ref. : 1007411
- EAN : 7045210131819
Description
Description
Standards
-
ProductIEC 60794
-
TestEN 50399 B2; IEC 60332-1; IEC 60332-3; IEC 60754-1; IEC 61034
This unibundle cable is designed for indoor/outdoor installation.
This cable has an outstanding fire behaviour.
This cable can be operated under a large temperature range.
Design
The SC-B2 LSZH* SP1766 cable has a central bundle with maximum 12 fibres inside. The design is reinforced by a layer of watertight glass yarns and a LSZH* sheath.
Fibre type
The SC-B2 LSZH* SP1766 cable is available with singlemode and multimode fibres.
Technical performances
The unibundle cable performances are specified in the following tables.
Additional details
This cable is provided as a standard with a black sheath, other sheath colours are also available. Long exposure to UV with these others colours could generate colour fading.
Euroclass
B2ca s1 d0 a1
* LSZH: Low Smoke Zero Halogen.
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Dimensional characteristics
Dimensional characteristics
Mechanical characteristics
Mechanical characteristics
Usage characteristics
Usage characteristics
Resources
Resources
Selling & delivery Information
Standard Marking
Nexans - FIBRE OPTIC CABLE - SC-B2 LSZH B2ca s1 d0 a1SP1766 - XXxYY - FB - TN - metric
XX = Fibre Count YY = Fibre Type FB = Frameries, Belgium (manufacturing place) TN = Traceability NumberOur websites
