TXLP/2R 120V Twin conductor heating cable units 17 W/m

Description

Description

Standards

  • Product
    IEC 60800
  • Test
    EN 50265; IEC 60332-1

Heating cable units for direct floor warming in concrete constructions. They can also be used in snow melting installations, for frost protection of roof gutters and drains, and soil heating. May be attached directly to reinforcement bars, preferably longitudinally.

Each unit has unique factory made integrated splices which is marked => SPLICE<= on the outer sheath.



Mechanical class M2 acc. to IEC 60800.



NB! This range is designed for use in 120 VAC systems only.

Characteristics

Characteristics

Construction characteristics

Construction characteristics

Drain wire
Tinned copper
Insulation
XLPE (chemical)
Outer sheath
PVC
Screen
Longitudinal aluminium tape + copper wire
Sheath colour
Blue
Type of conductor
Resistance alloy, solid
Type of splice
Intergrated/hidden

Dimensional characteristics

Dimensional characteristics

Approximate net weight
- kg
Nominal outer diameter
- mm

Electrical characteristics

Electrical characteristics

Nominal element resistance
- Ohm
Nominal output
- W
Operating voltage
120 V

Usage characteristics

Usage characteristics

Element length
- m
Output
17 W/m
Bending factor when laying
5 (xD)
Flame retardant
IEC 60332-1
Length of cold lead
- m
Max. temperature energized, outer sheath
65 °C
